RIBBED WIRE
Ribbed Wire
Ribbed wires are a specialised type of wire characterised by a series of regularly spaced ridges or ribs along its surface. These ribs significantly enhance the wire's surface area, providing superior adhesion properties when embedded in various matrices. The material composition of ribbed wires can vary, with the specific material selection determined by the intended application, corrosion resistance and desired mechanical strength. The rib profile, including the height, spacing, and shape, is carefully designed to optimise performance in terms of bond strength and overall structural integrity. The manufacturing process involves drawing the wire through a series of dies to achieve the desired diameter and rib pattern. This process ensures precise control over the wire's dimensions and surface characteristics.
FEATURES
Material
Made from mild steel rods, Nirmal ribbed wires excel in strength and durability.
Standards
Nirmal Prestressed concrete wires wires conform to BS EN 10218-2: 1997, MS 146: 2014
Tensile Strength
The tensile strength of Nirmal ribbed wires range between 500N/mm2-800N/mm2
Wire Diameter
Nirmal ribbed wires are available in various diameters ranging between 4.00-12.00 mm.
APPLICATIONS
Building Structures
Nirmal ribbed wires are embedded within concrete structures to significantly enhance their tensile strength. The ribs on the wire provide superior bond with the concrete, preventing cracks and improving overall structural integrity.
Reinforcement structures
Nirmal ribbed wires are used to tension concrete structures to induce compressive stresses, significantly enhancing their load-bearing capacity, stiffness, and durability. This improves overall structural performance, reduces deflection, and minimises the risk of cracking, especially under heavy loads and environmental factors.
Prefabricated Concrete Structures
Nirmal ribbed wire, when tensioned and anchored, imparts compressive stress to concrete components. This counteracts tensile stresses during loading, making the structures more durable and resistant to cracking.
Bridge Structures
Nirmal ribbed wires are used to prestress concrete girders, increasing their load-bearing capacity and reducing deflection. This results in longer lifespan and improved performance under heavy traffic loads.
Road Structures
Nirmal ribbed wire is employed to prestress concrete pavement slabs, enhancing their resistance to cracking caused by thermal stresses and heavy vehicular loads. This leads to smoother road surfaces and reduced maintenance costs.
QUALITY ASSURANCE
At every stage of production, we prioritise quality to deliver products and services that meet or exceed industry standards. Our commitment to quality assurance includes-:
Raw Material Inspection
Raw materials are thoroughly inspected to ensure quality is maintained.
In-Process Testing
Regular testing during the manufacturing process to verify adherence to specifications.
Final Inspection
Comprehensive quality checks on finished products, including dimensions, surface finish, and mechanical properties.
Certifications
Our products are certified in terms of quality and performance.
AFTER-SALE SERVICES
We are committed towards providing dedicated customer support at every stage of the purchase journey
Accountability
We assume full responsibility for any quality deficiencies and commit to prompt resolution.
Customer Support
Our dedicated support team is available to address any inquiries or concerns.
Choose Nirmal Ribbed Wires for your diverse needs, knowing that it is a reliable, versatile, and performance-driven solution. With a commitment to quality, precision manufacturing, and comprehensive after-sale support, Nirmal Ribbed Wires will meet and exceed your expectations in a wide range of applications.
